SKU: CYG-C12X2-500FT
Cyclone CYG-C12X2-500FT
Cyclone CYG-C12X2-500FT
Cyclone DC Power Cable Outdoor 12AWG 2-Conductor 500FT
Regular price
$762.50 USD
Regular price
Sale price
$762.50 USD
Unit price
per
Out of stock
Buy from Authorized Distributors
Couldn't load pickup availability
Cyclone CYG-C12X2-500FT
DC Power Cable Outdoor 12AWG 2-Conductor 500FT
The Cyclone CYG-C12X2-500FT DC Power Cable Outdoor 12AWG 2-Conductor 500FT THHN 600V 90°C Dry/Wet, Direct Burial, Sunlight Resistant, Aluminum Shield and Drain Wire, Overall Gas and Oil Resistant PVC Jacket.
Features:
- 12 AWG, 2-conductor DC power cable
- 500 ft length
- THHN rated for 600V
- 90°C temperature rating
- Suitable for dry and wet locations
- Direct burial rated
- Sunlight resistant
- Aluminum shield with drain wire
- Overall gas and oil resistant PVC jacket
- Designed for outdoor DC power applications
Specifications CYG-C12X2-500FT
| Conductor Data | |
| Size AWG | 12 |
| Stranding | 7 |
| PVC Insulation Thick. (Mils) | 15 |
| Nylon Armo (Mils) | 5 |
| Appr. O.D. (In) | .132 |
| Cable Data | |
| # of CDRS | 2 |
| AWG | 12 |
| OA Jacket Thick. (Mils) | 45 |
| Appr. O.D. (In) | .358 |
| Appr. Weight (Lbs./M Ft.) | 107 |
| Dimension | 16" x 12" x 12" inch |
| Weight | 44 lbs |
