SKU: CYG-C10X2
Cyclone CYG-C10X2
Cyclone CYG-C10X2
Cyclone Power Tray Cable 10AWG 2-Conductor Control and Power
Regular price
$2.13 USD
Regular price
Sale price
$2.13 USD
Unit price
per
16110 in stock
Cyclone CYG-C10X2
Power Tray Cable, 10 AWG, 2 Conductor, Control and Power, THHN, 600V, 90°C Dry/Wet, Sunlight Resistant, Direct Burial, Aluminum Shield and Drain Wire with an Overall Gas and Oil-Resistant PVC Jacket
Specifications CYG-C10X2
| Conductor Data | |
| Size AWG | 10 |
| Stranding | 7 |
| PVC Insulation Thick. (Mils) | 20 |
| Nylon Armo (Mils) | 5 |
| Appr. O.D. (In) | 167 |
| Cable Data | |
| # of CDRS | 2 |
| AWG | 10 |
| OA Jacket Thick. (Mils) | 45 |
| Appr. O.D. (In) | .428 |
| Appr. Weight (Lbs./M Ft.) | 142 |
| Dimension | 12" x 0.428" x 0.43" inch |
| Weight | 0.142 lb |
