Cyclone CYG-C10X1-500FT

Cyclone CYG-C10X1-500FT

Ground Cable Outdoor 10AWG 1-Conductor Type RHH 600V 500FT

Cyclone 10AWG Ground Cable is a high-performance, USA-made grounding and general-purpose wiring solution designed for demanding power and lighting applications. Engineered with 10 AWG 7-strand bare copper and durable XLPE (Cross-Linked Polyethylene) insulation, this cable delivers exceptional reliability, heat resistance, and long-term electrical stability. Rated for 1000V under RHH/RHW-2 or RW90 and 600V for USE-2 installations, it offers versatile compatibility across indoor, outdoor, and direct-burial environments.

This Cyclone ground cable features a .045” nominal insulation wall thickness and a .204” overall diameter, delivering excellent mechanical strength without added bulk. With an approximate weight of 45 lbs per 1,000 feet and copper content of 32.05 lbs per 1,000 feet, it balances ease of installation with rugged construction. Available in 100, 200, 300, 400, and 500-foot lengths, the cable ships with a clean black XLPE jacket for easy identification in the field.

Built to meet strict industry standards—including UL RHH/RHW-2/USE-2 and c(UL) RW90—this cable maintains reliable performance across extreme temperatures from -40°F to 194°F (-40°C to +90°C). Its ROHS-compliant materials make it a safe, environmentally responsible choice for contractors, electricians, and utility installers seeking long-lasting, code-compliant ground wiring.

Product Features

• 10 AWG 7-strand bare copper ground cable
• XLPE insulation for superior heat and abrasion resistance
• Voltage rating: 1000V (RHH/RHW-2/RW90), 600V (USE-2)
• Operating temp: -40°F to +194°F (-40°C to +90°C)
• Available in 100–500 ft lengths
• Made in the USA, ROHS compliant
• Ideal for power, lighting, grounding, and general electrical use

Specifications CYG-C10X1-500F
