SKU: CYG-C12X2
Cyclone CYG-C12X2
Cyclone CYG-C12X2
Cyclone Power Tray Cable 12AWG 2-Conductor Control and Power
Regular price
$1.68 USD
Regular price
Sale price
$1.68 USD
Unit price
per
12390 in stock
Cyclone CYG-C12X2
Power Tray Cable 12AWG 2-Conductor Control and Power
Power Tray Cable, 12 AWG, 2 Conductor, Control and Power, THHN, 600V, 90°C Dry/Wet, Sunlight Resistant, Direct Burial, Aluminum Shield and Drain Wire with an Overall Gas and Oil Resistant PVC Jacket
Specifications CYG-C12X2
| Conductor Data | |
| Size AWG | 12 |
| Stranding | 7 |
| PVC Insulation Thick. (Mils) | 15 |
| Nylon Armo (Mils) | 5 |
| Appr. O.D. (In) | .132 |
| Cable Data | |
| # of CDRS | 2 |
| AWG | 12 |
| OA Jacket Thick. (Mils) | 45 |
| Appr. O.D. (In) | .358 |
| Appr. Weight (Lbs./M Ft.) | 107 |
| Dimension | 12" x 0.358" x 0.36" inch |
| Weight | 0.107 lb |
